• Beschreibung
     04495-60051
     HRK2280
     Brake Shoe
     PCS

    Length:147.0 Width:60.0 Thicknes:4.0

Brake Shoe:04495-60051

Anwendung

Years
Engine Body
TOYOTA - Dyna / Toyoace
96.10~01.07
2000 LY161,162 LY161,162
01.07~07.08 2000 RZY220 RZY220
95.05~99.05 2800 LY161 LY161
99.05~01.07 3000 LY152,162 LY152,162
TOYOTA - Land Cruiser
84.11~90.01
3400 BJ70(V),BJ73V,B BJ70(V),BJ73V,BJ71V,BJ74V
90.01~94.01 3500 PZJ70(V),PZJ77H PZJ70(V),PZJ77HV,
90.01~92.08 4000 FJ75 FJ75
90.01~98.01 4200 HDJ81V,HZJ81V HDJ81V,HZJ81V
91.01~92.01 4200 HDJ80 HDJ80
92.01~99.08 4200 HZJ73,HZJ75 HZJ73,HZJ75
96.04~99.07 4200 HZJ70,73,77,79 HZJ70,73,77,79
96.04~01.08 4200 HZJ75 HZJ75
99.08~04.08 4200 HZJ71V HZJ71V
99.08~04.08 4200 HZJ76K(V) HZJ76K(V)
99.11~04.08 4200 HZJ77,HZJ79 HZJ77,HZJ79
92.08~98.01 4500 FZJ80G FZJ80G
90.04~99.08 4200 TD HZJ73,HZJ75,HZJ HZJ73,HZJ75,HZJ77HV
TOYOTA - Land Curiser 70 (Euro)
88.01~92.01
2400
92.01~97.01 2400
88.01~92.01 3000
92.01~97.01 3000
88.01~92.01 3500
92.01~97.01 3500
92.01~97.01 4000 FJ80(G) FJ80(G)
88.01~92.01 4200
92.01~97.01 4200
NISSAN - Atlas
07.06~
3000
NISSAN - Atlas, Atlac Condor
92.01~99.06
2000 SK4F23 SK4F23
99.06~ 2000 SH4F23 SH4F23
07.06~ 2000 SQ1F24,SQ2F24 SQ1F24,SQ2F24
92.01~97.08 2700 SP8F23 SP8F23
95.06~99.06 2700 SP4F23 SP4F23
07.06~ 3000 SZ1F24,SZ2F24 SZ1F24,SZ2F24
07.06~ 3000 SZ4F24,SZ5F24 SZ4F24,SZ5F24
97.08~ 3200 SR4F23,SR8F23 SR4F23,SR8F23
NISSAN - Cabstar
89.03~94.05
2000 F22,F23 F22,F23
89.03~97.07 2500 D F22,F23 F22,F23
NISSAN - PATROL / Ebro / Patrol GR
91.01~93.10
2800 260 260
91.01~96.03 2800 JYL/KYL/WYLG(26 JYL/KYL/WYLG(260)
91.01~93.10 3000 260 260
ISUZU - ELF
99.06~04.05
2000 ASH4F23 ASH4F23
97.08~ 3200 ASR8F23 ASR8F23
97.08~ 3200 ASR8F23 ASR8F23
99.06~ 3200 ASR2F23 ASR2F23
99.06~ 3200 ASR2F23 ASR2F23
07.01~ ALL



  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
