• Beschreibung
     04497-26050
     HRK2282
     Brake Shoe Set
     SET

    Rear Axle
    Brake System : AKEBONO
    Diameter : 254 mm
    Width : 50 mm

Brake Shoe Set:04497-26050
Model Engine Chassis Type CYL year
TOYOTA HIACE II Box (H5_)  5/84 - 1/89
TOYOTA HIACE II Wagon (H5_)  8/84 - 8/89
TOYOTA HIACE IV Wagon (_H1_, _H2_)  8/95 - 8/06
TOYOTA HILUX V Pickup (_N_, KZN1_, VZN1_)  8/89 - 7/97
TOYOTA LAND CRUISER (_J7_)  0/85 - 5/90
TOYOTA TACOMA II Pickup (RN6_, RN5_, LN6_, YN6_, YN5_, LN5_)  6/89 - 7/05

Anwendung

TOYOTA LAND CRUISER LJ71G 2400 85' 10-90' 1
TOYOTA HIACE LH71G 2400 87' 8-89' 8
TOYOTA HIACE LH61G 2400 87' 8-89' 8
TOYOTA HIACE YH61G 2000 87' 8-89' 8


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
