Brake Shoe Set:04495-26140--Fujian Huari Automotive Parts Co., Ltd.

Beschreibung
Ref.:	04495-26140
Huari No.:	HRK2317
Name:	Brake Shoe Set
Unit:	SET
Price:
Rear Axle Brake System : AKEBONO Diameter : 270m Width : 55 mm

Model	Engine			Type	CYL	year
DAIHATSU ROCKY Hard Top (F7, F8)					5/93 - 2/98
ROCKY Hard Top (F7, F8) 2.8 D (F70, F75, F80, F85)	DL	2765	73	Closed Off-Road Vehicle	4	2/85 - 2/98
ROCKY Hard Top (F7, F8) 2.8 TD (F70, F75, F80, F85)	DL 52	2765	102	Closed Off-Road Vehicle	4	9/91 - 2/98
ROCKY Hard Top (F7, F8) 2.8 TD	DL 52	2765	98	Closed Off-Road Vehicle	4	5/93 - 2/98
DAIHATSU ROCKY Soft Top (F7, F8)					9/91 - 2/98
ROCKY Soft Top (F7, F8) 2.8 D (F70, F75, F80, F85)	DL	2765	73	Open Off-Road Vehicle	4	2/85 - 2/98
ROCKY Soft Top (F7, F8) 2.8 TD	DL 52	2765	102	Open Off-Road Vehicle	4	9/91 - 2/98
TOYOTA HIACE III Box (_H10_)					8/89 - 8/95
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.0 (RCH102_, RCH112_)	1RZ	1998	101	Box	4	2/90 - 8/95
HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.4 D (LH10_, LH11_)	2L	2446	75	Box	4	8/89 - 8/95
TOYOTA HIACE III Wagon (_H10_)					8/89 - 8/95
HIACE III Wagon (_H1_) 2.0 (RZH102)	1RZ	1998	101	Bus	4	8/89 - 4/98
HIACE III Wagon (_H1_) 2.4 D (LH102)	2L	2446	75	Bus	4	8/89 - 8/95

Anwendung

DAIHATSU RUGGER F73 2800 93' 5-97' 5
DAIHATSU RUGGER F78 2800 93' 5-97' 5
TOYOTA LITE ACE CM52 2000 91' 10-99' 6
TOYOTA LITE ACE CM61 2000 91' 10-99' 6
TOYOTA TOWN ACE CM52 2000 91' 10-99' 6
TOYOTA TOWN ACE CM61 2000 91' 10-99' 6
TOYOTA HIACE LH123V 2800 89' 8-93' 8
TOYOTA HIACE LH125B 2800 89' 8-93' 8
TOYOTA HIACE LH115B 2800 89' 8-93' 8
TOYOTA HIACE RZH112V 2000 89' 8-93' 8
TOYOTA HIACE RZH110G 2000 89' 8-93' 8
TOYOTA HIACE RZH102V 2000 89' 8-93' 8
TOYOTA HIACE RZH100G 2000 89' 8-93' 8
TOYOTA HIACE RZH124B 2000 89' 8-93' 8
TOYOTA HIACE RZH122V 2000 89' 8-93' 8
TOYOTA HIACE LH140G 2400 90' 10-93' 8
TOYOTA HIACE RZH101G 2400 89' 8-93' 8
TOYOTA HIACE LH120G 2400 89' 8-93' 8
TOYOTA HIACE LH110G 2400 89' 8-93' 8
TOYOTA HIACE LH100G 2400 89' 8-93' 8
TOYOTA HIACE LH102V 2400 89' 8-93' 8

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
