Description 04497-26050 HRK2282 Brake Shoe Set SET Rear Axle
Brake System : AKEBONO
Diameter : 254 mm
Width : 50 mm
| Model | Engine | Chassis | Type | CYL | year | ||
|---|---|---|---|---|---|---|---|
| TOYOTA HIACE II Box (H5_) | 5/84 - 1/89 | ||||||
| TOYOTA HIACE II Wagon (H5_) | 8/84 - 8/89 | ||||||
| TOYOTA HIACE IV Wagon (_H1_, _H2_) | 8/95 - 8/06 | ||||||
| TOYOTA HILUX V Pickup (_N_, KZN1_, VZN1_) | 8/89 - 7/97 | ||||||
| TOYOTA LAND CRUISER (_J7_) | 0/85 - 5/90 | ||||||
| TOYOTA TACOMA II Pickup (RN6_, RN5_, LN6_, YN6_, YN5_, LN5_) | 6/89 - 7/05 | ||||||
Application
TOYOTA LAND CRUISER LJ71G 2400 85' 10-90' 1
TOYOTA HIACE LH71G 2400 87' 8-89' 8
TOYOTA HIACE LH61G 2400 87' 8-89' 8
TOYOTA HIACE YH61G 2000 87' 8-89' 8
TOYOTA HIACE LH71G 2400 87' 8-89' 8
TOYOTA HIACE LH61G 2400 87' 8-89' 8
TOYOTA HIACE YH61G 2000 87' 8-89' 8
- Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system - Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
- Rear brakes is recommended to replace within 5-7 km
- Replace the Disc brake when follow situation happen:
- 1.Sensor alarm;
- 2.Friction materials thickness less than 3mm;
- 3.Friction materials becomes contaminated with brake fluid;
- 4.Uneven wear within a set;
- Replace the brake rote when follow situation happen:
- 1.Vibrate when braking;
- 2.Car vehicle performance more than 60000Km and braking unstable;
- 3.Disc brake thickness wear more than 2mm;
