Descripción 55810-63J00 HR1023 Brake Pad Set SET Front Axle
Brake System : AKB
Width : 108.6 mm
Height : 45.3 mm
Thickness : 14.5 mm
| Model | Engine | Chassis | Type | CYL | year | ||
|---|---|---|---|---|---|---|---|
| CHANGAN (CHANA) CX20 Hatchback | 0/10 - 2/12 | ||||||
| SUZUKI SWIFT III (SG) | 8/05 - / | ||||||
| SUZUKI SWIFT IV (FZ, NZ) | 1/12 - / | ||||||
| SUZUKI (CHANGAN) SWIFT (EZ, MZ) | 2/07 - / | ||||||
Aplicación
SUZUKI Swift (Latin America) 2007-2010
- Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system - Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
- Rear brakes is recommended to replace within 5-7 km
- Replace the Disc brake when follow situation happen:
- 1.Sensor alarm;
- 2.Friction materials thickness less than 3mm;
- 3.Friction materials becomes contaminated with brake fluid;
- 4.Uneven wear within a set;
- Replace the brake rote when follow situation happen:
- 1.Vibrate when braking;
- 2.Car vehicle performance more than 60000Km and braking unstable;
- 3.Disc brake thickness wear more than 2mm;
