• Descripción
     4B0 698 151 M
     Brake Pad Set
     SET

    Front Axle
    Brake System : ATE
    Width : 156.3 mm
    Height : 74.1 mm
    Thickness : 20.6 mm

Brake Pad Set:4B0 698 151 M
Model Engine Chassis Type CYL year
AUDI A4 (8D2, B5)  1/95 - 1/00
AUDI A4 (8E2, B6)  1/00 - 2/04
AUDI A4 (8EC, B7)  6/06 - 6/08
AUDI A4 Avant (8D5, B5)  9/97 - 9/01
AUDI A4 Avant (8E5, B6)  9/01 - 2/04
AUDI A4 Avant (8ED, B7)  6/06 - 6/08
AUDI A4 Convertible (8H7, B6, 8HE, B7)  8/02 - 2/05
AUDI A6 (4B2, C5)  7/99 - 1/05
AUDI A6 Avant (4B5, C5)  2/98 - 1/05
VOLKSWAGEN PASSAT (3B2)  5/97 - 9/99
VOLKSWAGEN PASSAT (3B3)  2/01 - 5/05
VOLKSWAGEN PASSAT Variant (3B5)  6/97 - 1/00
VOLKSWAGEN PASSAT Variant (3B6)  5/02 - 8/05


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
