Brake Pad Set:251 698 151 D--Fujian Huari Automotive Parts Co., Ltd.

Описание
Ref.:	251 698 151 D
Name:	Brake Pad Set
Unit:	SET
Price:
Front Axle Brake System : ATE Width : 76.8 mm Height : 70 mm Thickness : 15.5 mm

Model	Engine			Type	CYL	year
VOLKSWAGEN TRANSPORTER II Box					8/75 - 7/79
TRANSPORTER II Box 1.6	AE	1584	50	Box	4	8/70 - 4/79
TRANSPORTER II Box 1.7	CA	1679	67	Box	4	8/71 - 2/73
TRANSPORTER II Box 2.0	GE	1970	69	Box	4	8/75 - 7/79
VOLKSWAGEN TRANSPORTER II Bus					8/75 - 4/79
TRANSPORTER II Bus 1.6	AD	1584	50	Bus	4	8/70 - 4/79
TRANSPORTER II Bus 1.7	CA	1679	66	Bus	4	8/71 - 0/73
TRANSPORTER II Bus 1.8	AP	1795	68	Bus	4	1/73 - 7/75
TRANSPORTER II Bus 2.0	CJ	1970	70	Bus	4	8/75 - 4/79
VOLKSWAGEN TRANSPORTER II Platform/Chassis					8/68 - 7/79
TRANSPORTER II Platform/Chassis 1.6	AS	1584	50	Platform/Chassis	4	8/68 - 7/79
VOLKSWAGEN TRANSPORTER III Box					8/85 - 7/92
TRANSPORTER III Box 1.6	CT	1584	50	Box	4	5/79 - 2/82
TRANSPORTER III Box 1.6 D	CS	1588	50	Box	4	1/81 - 7/87
TRANSPORTER III Box 1.6 TD	JX	1589	69	Box	4	0/84 - 7/92
TRANSPORTER III Box 1.6 TD Syncro	JX	1589	69	Box	4	3/86 - 7/92
TRANSPORTER III Box 1.9	DF	1913	60	Box	4	0/82 - 7/92
TRANSPORTER III Box 1.9	GW	1913	90	Box	4	8/83 - 2/89
TRANSPORTER III Box 1.9 Syncro	DG	1913	78	Box	4	1/84 - 7/92
TRANSPORTER III Box 2.0	CU	1970	69	Box	4	5/79 - 4/86
TRANSPORTER III Box 2.1	MV	2110	95	Box	4	8/85 - 7/92
TRANSPORTER III Box 2.1 Syncro	MV	2110	95	Box	4	8/85 - 7/92
VOLKSWAGEN TRANSPORTER III Bus					1/86 - 7/92
TRANSPORTER III Bus 1.6	CT	1584	50	Bus	4	5/79 - 2/82
TRANSPORTER III Bus 1.6 D	CS	1588	50	Bus	4	1/81 - 7/87
TRANSPORTER III Bus 1.6 TD	JX	1589	70	Bus	4	8/84 - 7/92
TRANSPORTER III Bus 1.6 TD Syncro	JX	1589	70	Bus	4	3/86 - 7/92
TRANSPORTER III Bus 1.9	DF	1913	60	Bus	4	8/82 - 7/92
TRANSPORTER III Bus 1.9	DH	1913	83	Bus	4	1/83 - 7/85
TRANSPORTER III Bus 1.9	GW	1913	90	Bus	4	8/83 - 7/85
TRANSPORTER III Bus 1.9 Syncro	DG	1913	78	Bus	4	2/85 - 7/92
TRANSPORTER III Bus 2.0	CU	1970	70	Bus	4	5/79 - 2/82
TRANSPORTER III Bus 2.1	MV	2110	95	Bus	4	8/85 - 7/92
TRANSPORTER III Bus 2.1 Syncro	MV	2110	95	Bus	4	8/85 - 7/92
TRANSPORTER III Bus 2.1 Syncro	DJ	2110	112	Bus	4	1/86 - 7/92
VOLKSWAGEN TRANSPORTER III Platform/Chassis					0/84 - 7/92
TRANSPORTER III Platform/Chassis 1.6 TD Syncro	JX	1589	69	Platform/Chassis	4	3/86 - 7/92
TRANSPORTER III Platform/Chassis 1.9	DG	1913	78	Platform/Chassis	4	8/82 - 7/92
TRANSPORTER III Platform/Chassis 1.9	DF	1913	60	Platform/Chassis	4	9/82 - 7/92
TRANSPORTER III Platform/Chassis 1.9 Syncro	DG	1913	78	Platform/Chassis	4	2/84 - 7/92
TRANSPORTER III Platform/Chassis 2.0	CU	1970	69	Platform/Chassis	4	5/79 - 4/86
TRANSPORTER III Platform/Chassis 2.1	MV	2110	95	Platform/Chassis	4	8/85 - 7/92
TRANSPORTER III Platform/Chassis 2.1 Syncro	MV	2110	95	Platform/Chassis	4	8/85 - 7/92
TRANSPORTER III Platform/Chassis 1.6 D	CS	1588	50	Platform/Chassis	4	1/81 - 7/87
TRANSPORTER III Platform/Chassis 1.6 TD	JX	1589	70	Platform/Chassis	4	0/84 - 7/92

По маркам автомобилей

PORSCHE 911 1970-1974
PORSCHE 911 Carrera 1988
PORSCHE 911 Turbo 1978-1979
VOLKSWAGEN Transporter 1973-1979
VOLKSWAGEN Vanagon 1980-1985

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
